Bradley S19224FWPT Stainless Steel Eye Face Wash Station with Plastic Bowl, Tailpiece & P Trap - Ideal for Medical Clinics, Laboratories & Industrial Use

✅ Halo™ Delivers the Most Effective Eye/Face Washdown Coverage and Spray Pattern

✅ Exceeds ANSI/ISEA Z358.1 Specifications

✅ Industry's Only Self-Draining Design – The Aquaduct™

✅ Separate Supply and Waste Pipes – Meets CEN and Plumbing Requirements

✅ Ergonomic Hand Activation Eyewash Paddle – Easy to Reach from Any Direction

✅ Barrier Free

✅ Fully-Assembled and Factory-Tested Eyewash or Eye/Face Wash with Hinged Dust Covers

✅ Universal Identification Sign and Inspection Tag Included

✅ Classified by Underwriters Laboratories Inc. to ANSI/ISEA Z358.1.

Bradley S19224FWPT Eye-Face Wash, Plastic Bowl, with Tailpiece & P-Trap, Complies with ANSI Standard Z358.1, Stainless steel tailpiece and p-trap, Galvanized steel supply & waste pipes protected with BRADTECT safety yellow coating, Universal identification sign and inspection tag included, Eye-Face Wash exceeds minimum water flow of 3 GPM at 30 PSI, Barrier-free design - fully accessible to people with physical disabilities, Formerly Halo model number S192240A1BAAD00.

Specifications
Standard Eye/Face Wash Units save space and fit easily into any work environment. Halo eye/face wash, operated by an ergonomic, highly visible push handle, provides effective wash down coverage and spray pattern. Integral strainer reduces debris in the water and also prevents clogging.

Pipe and Fittings
Piping to ½" NPT water supply inlet on unit. Piping to 1¼" NPT drain outlet for eyewash. 1¼" piping assembly manufactured of one of the following materials:
• Galvanized steel with BradTect® safety yellow coating

Ball Valve
½" stay-open eye and eye/face wash valve manufactured of the following materials:
• Chrome-plated brass

Eye/Face Wash
The Halo eye/face wash system offers a high performance rinsing platform that provides rapid relief to an individual’s eyes and face that have been injured by chemicals or particulate. This system provides the most complete face wash available in the market. The eye/face wash includes an integral 5.1 GPM (19.2 L) flow control, providing water at a safe velocity while maintaining its effectiveness (exceeds minimum water flow of 3.0 GPM (11.4 L) at 30 PSI (2.0 bar)). Eye/face wash is protected by flip open dust covers that open when product is activated. Safe, steady water flow under varying water supply conditions from 30–90 PSI (2.0-6.1 bar) is assured by integral flow control in the sprayhead assembly. Sprayheads are made from an impact resistant ABS plastic.

Activation
Type 304 stainless steel push handle.

Bowl
Bowl is constructed of yellow impact-resistant plastic

Wall Bracket
Heavy-gauge sand cast aluminum protected with BradTect safety yellow coating. Includes three clearance holes for mounting bracket onto wall (mounting hardware not included).

Waste
1¼" drain fitting and tailpiece furnished.
