Bradley S19224B Halo Eyewash Station with Stainless Steel Bowl - Wall Mounted Emergency Eye Wash for Laboratories, Workshops & Industrial Safety Use

✅ Complies with ANSI/ISEA Standard Z358.1

✅ Galvanized steel protected with BRADTECT safety yellow coating

✅ Stainless steel bowl

✅ Universal identification sign and inspection tag included

✅ Eyewash exceeds minimum water flow of 0.4 GPM at 30 PSI

✅ Barrier-free design - fully accessible to people with physical disabilities

The Bradley S19224B Wall Mount Emergency Eyewash is a durable wall-mounted eyewash unit that complies with American National Standard Z358.1-2014 performance requirements. The wall-mounted style is perfect for use in settings where tight conditions prevent the use of a freestanding eyewash model. The unit features a 10-3/4-inch bowl made of corrosion-resistant stainless steel and galvanized steel pipes covered with Bradtect yellow safety coating to make them highly visible.

Guaranteed with a one-year warranty from the manufacturer, the emergency eyewash features the Halo eyewash system, which is designed to completely flush the eyes with 4.3GPM of water at an optimal safe velocity. An antimicrobial agent is included in the unit to preserve the sanitary conditions of your facilities. To ensure that the water flows amply, but at a safe rate in the event of an emergency, the eyewash features integral flow control. The unit switches on easily with a stainless steel handle, which operates the chrome-plated brass 1/2-inch Ips stay-open ball valve. A safety sign and inspection tag are included with the Bradley S19224B Eyewash unit. This model is also known as the S192240A1ADAA00 and replaces the model S19-220B.

Specifications
Standard Eyewash Units save space and fit easily into any work environment. Halo eyewash, operated by an ergonomic, highly visible push handle, provides effective wash down coverage and spray pattern. Integral strainer reduces debris in the water and also prevents clogging

Pipe and Fittings
Piping to ½" NPT water supply inlet on unit. Piping to 1¼" NPT drain outlet for eyewash. 1¼" piping assembly manufactured of one of the following materials:
• Galvanized steel with BradTect® safety yellow coating

Ball Valve
½" stay-open eye and eye/face wash valve manufactured of the following materials:
• Chrome-plated brass

Eyewash
The Halo eyewash system offers a high performance rinsing platform that provides rapid relief to an individual’s eyes that have been injured by chemicals or particulate. The eyewash includes an integral 5.1 GPM (19.2 L) flow control, providing water at a safe velocity while maintaining its effectiveness (exceeds minimum water flow of 0.4 GPM (1.5 L) at 30 PSI (2.0 bar)). Eyewash is protected by flip open dust covers that open when product is activated. Safe, steady water flow under varying water supply conditions from 30–90 PSI (2.0-6.1 bar) is assured by integral flow control in the sprayhead assembly.

Activation
Type 304 stainless steel push handle.

Bowl
Bowl is constructed of Type 304 corrosion resistant stainless steel.

Wall Bracket
Heavy-gauge sand cast aluminum protected with BradTect safety yellow coating. Includes three clearance holes for mounting bracket onto wall (mounting hardware not included).

Waste
1¼" drain fitting and tailpiece furnished. Chrome-plated P-trap included with S19224BPT.


• Halo™ Delivers the Most Effective Eye/Face Washdown Coverage and Spray Pattern
• Exceeds ANSI/ISEA Z358.1 Specifications
• Industry's Only Self-Draining Design – The Aquaduct™
• Separate Supply and Waste Pipes – Meets CEN and Plumbing Requirements
• Ergonomic Hand Activation Eyewash Paddle – Easy to Reach from Any Direction
• Barrier Free
• Fully-Assembled and Factory-Tested Eyewash or Eye/Face Wash with Hinged Dust Covers
• Universal Identification Sign and Inspection Tag Included
• Classified by Underwriters Laboratories Inc. to ANSI/ISEA Z358.1.
